Data Sheet

Accessories for RACK cabinets - fan panel for floor- standing cabinets
Pulsar
®
RAWP v1.0/IV
Panel of two fans for RACK cabinets of the RS / ZRS type
CODE:
NAME:
APPLICATION
The fan panel is to be mounted in the top plate of RACK cabinet. It forces air circulation inside the cabinet. It is mounted outside of
the RACK cabinet. The set includes a detachable 230VAC wire.
TECHNICAL DATA
Dimensions: W=297, H=149, D=47 [mm, +/-2]
0,1÷0,12A
Net/gross weight: 1,48 / 1,58 [kg]
Finish: - 1,2mm cold rolled steel sheet (SPCC), color RAL 9004
- Two 230VAC fans with a capacity of 2 x 50÷110CBM/H
Application: Indoor
Notes: - Mounting to the top plate of RACK cabinet
- The possibility of cascade connection of fans
- 230VAC LZ=2m wire
- Designed for version 1.2 of the RACK floor standing cabinets with depths of 600 ÷ 1000mm
Rated voltage: 220÷240V AC / 50/60Hz
Rated current:
Phone [phone], Fax [phone], www.pulsar.pl, E-mail: [e-mail]
EN*
H
W
Mounting to the top plate of RACK cabinet
End caps Removed caps Mounted fan
The possibility of cascade connection of fans
RACK 19" cabinet depth:
600mm 800mm 1000mm
1x RAWP
2x RAWP
2x RA
3x RAWP
