Data Sheet

PSDCSEP08128 v.1.0/I
adjustable for each channel.
PSDCSEP 12V/8A/8x1A/TOPIC Power supply for up to 8 HD cameras,
CODE:
TYPE:
EN**
wyjście TAMPER : przewody 30cm
Tel. [phone], fax: [phone], www.pulsar.pl, e-mail: [e-mail]
PSDCSEP series power supply unit
12V DC Power supply for up to 8 HD cameras, adjustable for each channel
DESCRIPTION
The PSDCSEP08128 stabilized power supply is designed to supply HD cameras or other devices
requiring stabilized voltage of 12V DC. The power supply has 8 independently adjustable channels with
selectable voltages in the range 12V÷15V DC / 8x1A, thus compensating voltage drops in large CCTV
installations. Power supply outputs are galvanically separated and protected by fuses. A failure (short circuit) in
the output circuit will cause the fuse to blow and disconnect the circuit from DC power (+ U).
Features:
· the 8x1A/12V DC power output for powering
HD cameras
· output voltage adjustment 12V÷15VDC
· wide range of supply voltage 85÷264VAC
· 8 independent, galvanically separated outputs
· 8 outputs protected independently by 1A fuses
· high efficiency 81%
· protections:
· SCP short-circuit protection
· OVP over voltage protection
· surge protection
· OLP overload protection
· warranty – 2 year from the production date
W
H
D
W
1
H
1
D
1
