PSDC 161214 v.1.1 PSDC 12V/14A/16x1A Power supply for up to 16 HD cameras - PTC/TOPIC. EN* Edition: 10 from 11.10.2017 Supersedes the edition: 9 from 24.04.
www.pulsar.
www.pulsar.pl PSDC161214 1. Technical description. 1.1 General description. The PSDC161214 stabilized power supply is designed to supply HD cameras or other devices requiring stabilized voltage of 12V DC. The output voltage adjustment range is adjusted via a potentiometer within the range of 12V÷15V DC. The PSU features 16 outputs protected independently by either glass fuses or polymer fuse.
www.pulsar.pl PSDC161214 Fig.2. The view of the PSU’s PCB. Table 2. Elements of the PSU (see fig. 3). Element no.
www.pulsar.pl PSDC161214 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3).
www.pulsar.pl PSDC161214 Operating specifications (tab.6). Operating temperature Storage temperature Relative humidity Vibrations during operation Impulse waves during operation Direct insolation Vibrations and impulse waves during transport -10ºC...+40ºC -25ºC...+60ºC 20%...90%, without condensation unacceptable unacceptable unacceptable PN-83/T-42106 2. Installation. 2.1 Requirements.
www.pulsar.pl PSDC161214 3.1. LED indication (fig.4.). • LED1…LED16 green diodes indicate power at the outputs: LB8-A AUX1…AUX8, LB8-B AUX1…AUX8. In case of a power loss at the output (fuse activation), an appropriate diode goes out. (L1 for AUX1, L2 for AUX2 etc.) • LFPS red LED [!] indicates a failure of at least one AUX output (the output’s number is indicated by the green diode). Fig. 4. The view of the PSU panel. 3.2 Technical outputs.
www.pulsar.pl PSDC161214 WEEE MARKING According to the EU WEE Directive – It is required not to dispose of electric or electronic waste as unsorted municipal waste and to collect such WEEE separately. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.
