PSDC161212T v.1.1 PSDC 12V/12A/16x0,8A/TOPIC Power supply for up to 16 HD cameras. EN Edition: 6 from 19.10.2017 Supersedes the edition: 5 from 24.04.
www.pulsar.pl PSDC161212T Features: • • • • • • • protections: • SCP short-circuit protection • OVP over voltage protection • surge protection • OLP overload protection • warranty – 2 year from the production date the 16x0,8A/12V DC power output for powering 16 HD cameras output voltage adjustment 12V÷15V DC 16 outputs protected with 0,8A fuses wide range of supply voltage 176÷264V AC high efficiency 83% LED indication Example of power supply of up to 16 HD cameras.
www.pulsar.pl PSDC161212T 1. Technical description. 1.1 General description. The PSDC161212T stabilized power supply is designed to supply HD cameras or other devices requiring stabilized voltage of 12V DC. The output voltage adjustment range is adjusted via a potentiometer within the range of 12V÷15V DC. The PSU features 16 outputs protected independently by glass fuses.
www.pulsar.pl PSDC161212T Fig.3. The view of the PSU. 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3).
www.pulsar.pl PSDC161212T Mechanical specifications (tab. 4). W=290, H=256, D+D1=52+8 [+/- 2 mm] Dimensions W 1=294, H1=260 [+/- 2 mm] Fixing See figure 3 Net/gross weight 2,0/2,2 kg Enclosure Steel plate, DC01 0,7mm colour: RAL 9003 Closing Cheese-head screw: at the front Connectors Power supply: 230V AC: Φ0,63-2,05 (AWG 22-12) AUX outputs: Φ0,51- 2,05 (AWG 24-12) LB8 (A, B): Φ0,51- 2,05 (AWG 24-12) Notes The enclosure does not adjoin the assembly surface so that cables can be led. Convectional cooling.
www.pulsar.pl PSDC161212T 4. Connect the receivers’ cables to the AUX1…AUX8 connectors on the LB8 (A, B) strips. 5. In electrical installations with significant voltage drops in the resistance of the wires that lead to the receivers, the voltage value can be corrected with the P1 potentiometer (12V÷15V DC). 6. Check the PSU operating status indication 7. Once the installation and operation control have been completed, the enclosure can be locked. 3. Operating status indication.
