PSDC 08128 v.1.3 PSDC 12V/8A/8x1A Power supply for up to 8 HD cameras - PTC/TOPIC. EN** Edition: 12 from 11.10.2017 Supersedes the edition: 11 from 24.04.
www.pulsar.
www.pulsar.pl PSDC08128 1. Technical description. 1.1 General description. The PSDC08128 stabilized power supply is designed to supply HD cameras or other devices requiring stabilized voltage of 12V DC. The output voltage adjustment range is adjusted via a potentiometer within the range of 12V÷15V DC. The PSU features 8 outputs protected independently by either glass fuses or polymer fuse.
www.pulsar.pl PSDC08128 Fig. 2. The view of the PSU’s PCB. Table 2. Elements of the PSU (see fig. 3). Element no. [1] [2] [3] [4] Description L-N 230V AC power connectors, PE protection connector LED indication of DC power status, main module of the PSU PSU module VADJ, potentiometer, output voltage adjustment within the range of 12V÷15V DC [5] LB8/AW fuse strip, with power outputs and LED indication [6] Tamper, contact of tampering protection (NC) Fig.3. The view of the PSU.
www.pulsar.pl PSDC08128 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3).
www.pulsar.pl PSDC08128 Operating specifications (tab.6). Operating temperature Storage temperature Relative humidity Vibrations during operation Impulse waves during operation Direct insolation Vibrations and impulse waves during transport -10ºC...+50ºC -25ºC...+60ºC 20%...90%, without condensation unacceptable unacceptable unacceptable PN-83/T-42106 2. Installation. 2.1 Requirements.
www.pulsar.pl PSDC08128 3.1. LED indication (fig. 4.). • LED1…LED8 green diodes indicate power at the outputs: LB8- AUX1…AUX8. In case of a power loss at the output (fuse activation), an appropriate diode goes out. (L1 for AUX1, L2 for AUX2 etc.) • LFPS red LED [!] indicates a failure of at least one AUX output (the output’s number is indicated by the green diode). Fig. 4. The view of the PSU panel. 3.2 Technical outputs.
www.pulsar.pl PSDC08128 WEEE MARKING According to the EU WEE Directive – It is required not to dispose of electric or electronic waste as unsorted municipal waste and to collect such WEEE separately. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.
