Mechanical Specification
70
58.4
54.5
90
63.65 45.15
1 2
3 4 5 6
(Unit: mm , tolerance ± 0.5mm)
Installation Manual
Please refer to : http://www.meanwell.com/manual.html
Terminal Pin No. Assignment
Pin No.
Pin No.
1
Assignment
Assignment
AC/N
AC/L
ADMISSIBLE DIN-RAIL:TS35/7.5 OR TS35/15
35
+V
-V
2
3,4
5,6
