Operating instructions

www.pulsar.pl EN54-3A28 RED POWER
37
Fuses:
- F
MAINS
- F
BAT
- F
AUX1
- F
AUX2
T 3,15A / 250V
F 6,3A / 250V
F 5A / 250V
F 5A / 250V
Additional equipment
(not included)
- USB-TTL „INTU” interface; USB-TTL communication
- RS485 „INTR” interface; RS485 communication
- USB-RS485 „INTUR” interface; USB-RS485 communication
- Ethernet „INTE” interface; Ethernet communication
- WiFi “INTW” interface; WiFi wireless communication
- RS485-Ethernet “INTRE” interface; RS485-Ethernet
communication
- RS485-WiFi “INTRW” interface; RS485-WiFi wireless
communication
Table 13. Mechanical parameters.
Enclosure dimensions 420 x 420 x 182 (WxHxD) [mm] (+/- 2)
Mounting 380 x 345 x Φ 6 x4 pieces (WxH)
Recommended battery model - 2 x EP 17-12 or
- 2 x GP12170
Net/gross weight 10,3/11,6 kg
Enclosure Steel plate DC01 1,2mm, color: RAL 3001 (red)
Closing Key lock
Terminals Mains supply: Ф0,51÷2 (AWG 24-12)
Outputs : Ф0,51÷2 (AWG 24-12)
Battery outputs BAT: Ф6 (M6-0-2,5)
Cable glands PG9 – cable diameter Ф4÷8mm
PG11 – cable diameter Ф5÷10mm
Notes The enclosure does not adjoin the mounting surface so that cables can be led.
Convection cooling.
Table 14. Safety of use.
Protection class PN-EN 60950-1:2007 I (first)
Protection grade PN-EN 60529: 2003 IP44
Insulation electrical strength:
- between input (network) circuit and the output circuits of the PSU (I/P-O/P)
- between input circuit and PE protection circuit (I/P-FG)
- between output circuit and PE protection circuit (O/P-FG)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
Insulation resistance:
- between input circuit and output or protection circuit 100 MΩ, 500V/DC
Table 15. Recommended types and sections of installation cables.
Mains supply 230V AC L-N-PE
(see Table 2 [2])
OMY 3 x 0,75 mm
2
…1,5 mm
2
AUX1, AUX2 output terminals
(see Table 1 [11])
HLGs 2 x 1,5 mm
2
…2,5 mm
2
Indication inputs/outputs
(see Table 1 [11])
YnTKSY 1 x 2 x 0,8 mm
2
Additional indication lines (with optional interface) FTP 4x2x0,5 cat. 5e
