Specifications

QUANTUM
Quantum HD 38 Quantum LD 38 |
| Quantum HSQ 19 Quantum LSQ 19
THERMAL IMAGING DEVICES
 Long Viewing Range
 Germanium Lens with Internal Focusing
 Wide Range of Operation Temperatur
 Effective Operation in Fog or Smoke Conditions
 High Contrast Frost-resistant OLED Display
 Constant Image Quality Across the Entire Field of View
 User Sensor Calibration
 Brightness and Contrast Settings
 User Choic
 Quick Start-up
 External Power Supply Availability
 Video Out (video Recording Capability)
 Weaver MIL-STD-1913 Rail to Install Accessories
(Video Recorder, External Power Supply etc.)
 Partially rubberized nylon composite body
 Two ¼ Inch Sockets
 Lightweight and Compact Dimensions
30 Hz
9 Hz
DESCRIPTION
SUFFICIENT OPTICAL MAGNIFICATION
Optical magnification of the Quantum series units varies
from 2x to 2.1x. Models Quantum HD38 and LD38 are
additionally outfitted with two power digital zoom.
CONTROLS
Main control functions (turning on and off the unit,
sensor calibration, colour inversion/digital zoom) are
with the buttons on the upper panel. The size
and location of the buttons are customised for
comfortable use both with a gloved or bare hand.
QUICK START-UP
The Quantum is ready to operate in less than 10
seconds after it is turned on.
EXTRA OPTIONS
VIDEO OUTPUT
All Quantum models are equipped with an analog video
output to enable connection of external recording
equipment or transmitting image to the display.
WIDE RANGE OF OPERATION TEMPERATURES
Quantum monoculars are effective for the use in low
temperatures (-20°C) thanks to the frost-resistant
OLED display employed in the unit (image remains the
same as when viewing at positive temperature of the
surrounding atmosphere).
SELF-CONTAINED POWER SUPPLY
The Quantum is powered with four AA (rechargeable)
batteries. The batteries are stored in a container which
is then placed in a battery compartment of the unit.
EXTERNAL POWER SUPPLY
Operation time of the unit can be significantly increased
thanks to the use of external power supplies (for
example, Pulsar EPS3/EPS5) that can be connected
with a special jack. When used in frosty weather, the
power supply can be stored under the clothes.
LED INDICATION
A LED indicator shows current operating status of the
thermal imaging scope: the LED indicator means the
unit is on; colour changes to red when battery level is
low; after that the unit still keeps working for about
30 minutes before the batteries are completely
exhausted.
BODY
Partially rubberized nylon composite body featuring extra
durability ensures secure grip of the unit.
5
activated
The Quantum’s menu includes brightness/contrast
settings, running time setup and video output signal
selection. All information on operation mode including
battery level information is shown on a high contrast
OLED display on the data panel under the image.
