Specifications

NITROGEN PURGED OPTICAL PATH
The Phant s housing is rugged and reliable due to
cits onstruction of high-grade, glass-filled, plastic
composite. The unit can operate in any weather
condition. Unique for Night Vision, nitr its ogen-purged
optical channel prevents fogging caused by
temperature drops or high humidity.
MIL-DOT RETICLE
The standard Phantom features a red-on-green reticle
with brightness control. The Phantom MD features a
selectable, two-color, red-on-green or green-on-red
reticle MilDot reticle. Blinking reticle indicates that the
battery should be placed be within the 15-30 minutes.
REMOTE CONTROL
DESCRIPTION
PHANTOM
Phantom 3x50 MD Phantom 4x60 MD|
NIGHT VISION RIFLESCOPES
 Fine Image Quality and Resolution
 Multi-Reticle or Switchable Two-Color Mil-Dot Reticle Options
 50 Cal. Ready
 Nitrogen Purged Optical Path
 Rugged and Water-Resistant to IPX6 Standard
 Stabilized Power Supply Unit
 Functions with One AA (1.5V) or CR123A (3V) Battery
 Low Battery Indicator
 Instant On Function
 Internal Focus Adjustment
 Ergonomic Design and Easy-to-Use Interface
 Remote Control with Secure Attachment
 Additional Weaver MIL-STD-1913 Rail for Accessories
 Manufacturing Employs Composite Plastic and Other Modern Technologies
 Flip-Up Objective Lens Cover
or
BUILT-IN IR ILLUMINATOR
The Phantom has a powerful removable IR
illuminator offering a variable beam from spot to flood.
INTERNAL FOCUSING
PROTECTIVE LENS CAP
WEAVER 7/8" RAIL
POWER SUPPLY
GLOW OF TUB
CREEN
The Phantom (Gen.2+ models) are equipped with image
intensifier tubes with various glow of the scr
regular green or black and white (model Phantom BW)
with enhanced contrast.
11
GEN 2+
GEN 3
The included remote control has three buttons to
duplicate the on-and-off function of the device and IR
illuminator. The third button is intended for a quick
start-up of the riflescope and the IR illuminator works only
when the button is kept pressed. This function is very
convenient when constant observation is not required or
you just want the IR on momentarily.
The Phantom's focusing mechanism operates via a
positive click-stopped focus wheel on the right side of the
housing that allows focusing from 8m to infinity. The
focusing provides clear images at extremely short
distances, as well as optimizing quality at all distances
within the riflescope's effective working range.
A soft rubber cap with a pinhole for testing in daylight is
securely attached to the housing of the Phantom 4x60
Gen 3 Riflescope and protects the lens from water,
scratches, and chips when the scope it is not in use.
When using the riflescope, simply slide the lens cap back
along the side of the housing.
The Phantom can be powered with either a 1 AA (1.5V) or
1 CR123A lithium battery. The stabilized voltage of the
power supply system ensures correct operation, even
when the battery is nearly depleted and also prevents
reticle brightness changes. Vertical positioning of the
battery compartment enhances reliability of energy
supply when recoil occurs during shooting.
The Phantom is equipped with a weaver 7/8” rail on the
left side of the body, allowing for mounting of additional
accessories (IR flashlight, DSAS, lasers, etc.).
