Data Sheet

Tel. [phone], fax: [phone], www.pulsar.pl, www.zasilacze.pl, e-mail: [e-mail]
Casings universal - surface mounted
Pulsar
®
AWO229
Enclosure
v1.2/IV
17/EXP/SAT/GRADE 3
CODE:
NAME:
APPLICATION
1.
SATEL: INT-E, INT-PP, ACCO-NT, ACCO-KP, ACCO-KPWG, ACCO-KP-PS, ACCO-KPWG-PS.
2.
SATEL: APS-412, APS-612.
PULSAR: PSB251215, PSB351225, PSB501235, PSB751250.
Modules:
Buffer power supply units:
TECHNICAL PARAMETERS
External dimensions of the enclosure: W=330, H=305, D=120 D =15 [+/- 2mm]
1
Weight net/gross: 3,15kg / 3,40kg [+/-0,1kg]
Battery space: 17 Ah/12 V Sealed Lead Acid (SLA)
Notes:
Closing: screwed x 2
Tamper protection: enclosure is equipped with set including mounting bracket with tamper
Destination: indoor
Material description: sheet steel DC01, thickness: 1,0mm, corrosion protection, color : RAL 9003
Operating environment: 2nd environmental class, -10°C÷ 40°C
distance from wall (mounting sourface) - 15mm, "C”-shaped doors and the bottom of the
casing, no hinges
Declaration, w : RoHS,
arranty
2 year from the production date
in accordance with the EN50131 standard, Grade 3
External dimensions of the front panel: W =325, H =310 [+/- 2mm]
1 1
W
1
H
D
W
H
1
D
1
