ML60.121
MiniLine-2
12V, 4.5A, SINGLE PHASE INPUT
15. PROTECTION FEATURES
Output protection Electronically protected against overload, no-load and short-circuits *)
Output over-voltage protection typ. 18Vdc
max. 19Vdc
In case of an internal power supply fault, a redundant
circuit limits the maximum output voltage. In such a
case, the output shuts down and stays down until the
input voltage is turned off and on again.
Output over-current protection electronically limited see Fig. 5-1
Degree of protection IP 20 EN/IEC 60529
Penetration protection > 2.5mm in diameter e.g. screws, small parts
Over-temperature protection not included
Input transient protection MOV Metal Oxide Varistor
Internal input fuse T3.15A H.B.C. not user replaceable
*) In case of a protection event, audible noise may occur.
16. SAFETY FEATURES
Input / output separation
*) SELV IEC/EN 60950-1
PELV IEC/EN 60204-1, EN 50178, IEC 62103, IEC 60364-4-41
Class of protection I PE (Protective Earth) connection required
II (with restrictions) for use without PE connection contact PULS
Isolation resistance > 5MOhm Input to output, 500Vdc
Touch current (leakage current) typ. 0.13mA / 0.29mA 100Vac, 50Hz, TN-,TT-mains / IT-mains
typ. 0.19mA / 0.40mA 120Vac, 60Hz, TN-,TT-mains / IT-mains
typ. 0.30mA / 0.63mA 230Vac, 50Hz, TN-,TT-mains / IT-mains
< 0.17mA / 0.38mA 110Vac, 50Hz, TN-,TT-mains / IT-mains
< 0.25mA / 0.53mA 132Vac, 60Hz, TN-,TT-mains / IT-mains
< 0.41mA / 0.85mA 264Vac, 50Hz, TN-,TT-mains / IT-mains
*) Double or reinforced insulation
Nov. 2015 / Rev. 1.4 DS--ML60.121-EN
All parameters are specified at 12V, 4.5A, 230Vac 50Hz input, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
