WORKABOUT PRO Hand-Held Computer With Windows Mobile 6 Classic & Professional User Manual 317
Chapter 8: Specifications
HHP5180 Imager
8.5.3.1 HHP5180 Imager Decode Zone
Symbologies supported
2D: PDF417, MicroPDF417, MaxiCode, Data Matrix, QR
Code, Aztec, Aztec Mesa, Code 49, UCC Composite
Linear: Code 39, Code 128, Codabar, UPC, EAN, Interleaved
2 of 5, RSS, Code 93, Codablock
Postal: Postnet (US), Planet Code, BPO 4 State, Canadian
Post, Japanese Post, KIX (Netherlands) Post
OCR Fonts: OCR-A, OCR-B
Size
1.78cm Depth x 2.79cm Width (without mounting tabs) x
1.21cm Height
0.7 in. Depth x 1.1 in. Width (without mounting tabs) x 0.475
in. Height
Weight 5.9 grams (.21 ounces)
Operational Input Voltage:
Imager: 3.3 VDC ±5% (23°C)
Illumination + Aimer 5300: 3.0 VDC to 5.5 VDC (23°C)
Current Draw:
Imager: Operating Current – 100 mA
Standby Current: 100 µA
Operating Temperature -30° to +50°C (-34° to 122°F)
Storage Temperature -40° to +70°C (-40° to 158°F)
Humidity up to 95% RH, non-condensing at 122° F (50°C)
Shock 18 shocks of 3,500 G for 0.5 msec at 23°C (73° F)
Performance
Focal Point
SR
7 inches (17.8 cm) from lens plate
SF
4.5 inches (11.4 cm) from lens plate
SR Working
Range*
8.3 mil Linear
(.020 cm)
10 mil PDF417
(.025 cm)
13 mil UPC
(.033 cm)
15 mil Data
Matrix
(.038 cm)6
15 mil QR
(.038 cm)
35 mil
Maxicode
(.089 cm)
Near
3.5 in.
(8.9 cm)
3.1 in.
(7.9 cm)
2.1 in.
(5.3cm)
2.3 in.
(5.8 cm)
2.1 in.
(7.9 cm)
2.0 in.
(5.1 cm)
Far
7.6 in.
(19.3cm)
9 in.
(22.9 cm)
13.2 in.
(33.5 cm)
10.2 in.
(25.9 cm)
8.8 in.
(22.4 cm)
13.0 in.
(33 cm)
Parameter HHP5180
