WORKABOUT PRO Hand-Held Computer With Windows Mobile 6 Classic & Professional User Manual 279
Chapter 7: Peripheral Devices & Accessories
Cigarette Lighter Adaptor–Model #WA3113-G2
7.7 Cigarette Lighter Adaptor–Model #WA3113-G2
Important: It is critical that you review the safety instructions outlined in the
quick start guide enclosed with your cigarette lighter adaptor
before using the accessory.
The cigarette lighter adaptor allows you to power your hand-held and recharge your
battery using power drawn from your vehicle’s cigarette lighter outlet.
Figure 7.5 Cigarette Lighter Adaptor
• Unscrew the adaptor end-cap, and remove the fuse inside the adaptor.
• Replace it with the fuse provided with your kit, and screw the adaptor end-
cap back into position.
• Insert the DC power plug into the DC IN socket at the base of the WORK-
ABOUT PRO.
Insert the cigarette lighter adaptor plug into cigarette lighter outlet in your vehicle.
7.8 Single Battery Charger–Model #WA3001-G1
Figure 7.6 Single Battery Charger
DC Power Plug
Cigarette Lighter
Adaptor Plug
Adaptor End-Cap
