WORKABOUT PRO Hand-Held Computer With Windows Mobile 6 Classic & Professional User Manual 271
Chapter 7: Peripheral Devices & Accessories
The Batteries
• Insert the belt in the swivel holster pad.
• Attach the pad on either the left or right side of the holster case, depending
on whether you are left- or right-handed.
• Fasten the belt comfortably around your waist. Slide the adjustable ring on
the belt to tighten the holster in place.
• Connect the safety tether cord to one of the clips on the bottom of the soft
shell holster. Connect the other end to the hole in the end of the WORK-
ABOUT PRO pistol grip. This tether will catch the unit in case of a drop.
The tether can be adjusted to the operator’s height. The clips will break
away in case of a severe force.
7.2 The Batteries
Note: Review “Specifications” on page 295 for detailed information.
The WORKABOUT PRO will operate with any of the following Lithium-Ion
battery packs:
• High-Capacity – Model WA3006
• Super High-Capacity – Model WA3010
In addition to the main battery, the hand-held is equipped with a replaceable,
rechargeable Lithium-Ion backup battery.
7.3 Adaptor Cable Options
The following are adaptors can be ordered for your WORKABOUT G2:
7.4 Chargers And Docking Stations
Important: Keep in mind when ordering a charger or docking station, you
must also order the appropriate power cord separately.
Model Number Adaptor Cable Description
WA1002
Tether to USB device. This cable is used to connect USB
devices such as USB Flash memory devices.
WA4020-G2 Tether to RS232. This is a full RS232 port on COM2.
WA4001-G2 Tether to USB Client. (For ActiveSync)
WA4010-G1 USB to Ethernet adaptor.
WA4015
USB/RS232 adaptor. This cable is used with docking station
WA4003-G2.
