Psion Teklogix WORKABOUT PRO With Windows Mobile 2003 SE User Manual 163
Chapter 6: Settings
Advanced Modem Settings
Parity
This parameter determines the type of parity checking used on the data going
through the port. The options are: none, odd, even, mark and space.
Stop Bits
This parameter specifies the number of stop bits–1, 1.5, 2–used for asynchronous
communication.
Flow Control
This parameter selects the type of flow control used in your hand-held computer.
The WORKABOUT PRO can perform Software or Hardware handshaking, or you
can choose
None.
Terminal
The Terminal settings along with your modem allows your WORKABOUT PRO to
connect to an online service or a corporate server that requires TTY or VT-100
terminal emulation. You could, for example, connect to other computers, Telnet sites
and host computers. This option is similar to the HyperTerminal program
capabilities on your PC.
TCP/IP Settings
Figure 6.69 TCP/IP Tab
Important: If your server assigns IP addresses dynamically, you will not need
to change these settings. If you need to make changes, contact
your ISP or network administrator for addresses.
