Chapter 10: Specifications
Scanner Specifications
332 WORKABOUT PRO Hand-Held Computer With Windows Mobile 5.0 User Manual
RX Sensitivity -80dBm max
(BER<=0.1%)
Data Rate 732.2kbps and 57.6kbps asymmetric,
433.9kbps symmetric
10.3 Scanner Specifications
10.3.1 SE 1223HP, LR, ALR And SE 955HP Specifications
Scan Engine SE 1223HP SE 1223LR SE 1223ALR SE 955HP
Scan Angle 42º ± 2º 23º ± 2º 13º ± 2º
47° ± 3° default /
35° ± 3° reduced
Scan Rate
35 (± 5) scans/sec
(bi-directional)
35 (± 5) scans/sec
(bi-directional)
35 (± 5) scans/sec
(bi-directional)
104 (± 12)
scans/sec
(bi-directional)
Scan Pattern Linear Linear Linear Linear
Wavelength 650nm 650nm 650nm 650nm
Input Voltage 5.0 VDC ± 10% 5.0 VDC ± 10% 5.0 VDC ± 10%
3.0-5.5 VDC ±
10%
Input Current 110 mA typical 115 mA typical 115 mA typical 65 mA typical
Standby Current 130 µA typical 70 µA max. 70 µA typical 8 µA max
Operating
Temperature
-40ºC to 60ºC
-40ºF to 140ºF
-30º to 55ºC
-22ºF to 131ºF
-30°C to 55°C
-22ºF to 131ºF
-20° to 60° C
-4° to 140° F
Print Contrast
Minimum 20%
absolute dark/light
reflectance mea-
sured at 650 nm
Minimum 40%
absolute dark/light
reflectance mea-
sured at 650 nm
Minimum 40%
absolute dark/light
reflectance mea-
sured at 650 nm
Minimum 25%
absolute dark/light
reflectance mea-
sured at 650 nm
Dimensions
1.93 cm max. H x
3.84 cm max. W x
3.51 cm max. D
0.76 in. max. H x
1.51 in. max. W x
1.38 in. max. D
1.93 cm max. H x
3.84 cm max. W x
3.51 cm max. D
0.76 in. max. H x
1.51 in. max. W x
1.38 in. max. D
1.93 cm max. H x
3.84 cm max. W x
3.51 cm max. D
0.76 in. max. H x
1.51 in. max. W x
1.38 in. max. D
1.21 cm H x 2.16
cm W x 1.55 cm
(max)
0.47 in. H x 0.85
in. W x 0.61 in. D
(max)
Symbologies
UPC/EAN, Code
128, Code 39,
Code 93, I 2 of 5,
Discrete 2 of 5,
Codabar, MSI
UCC/EAN 128,
TriOptic Code 39
UPC/EAN, Code
128, Code 39, Code
93, I 2 of 5, Dis-
crete 2 of 5,
Codabar, MSI
UCC/EAN 128,
TriOptic Code 39
UPC/EAN, Code
128, Code 39,
Code 93, I 2 of 5,
Discrete 2 of 5,
Codabar, MSI
UCC/EAN 128,
TriOptic Code 39
UPC/EAN, Code
128, Code 39,
Code 93, I 2 of 5,
Discrete 2 of 5,
Codabar, MSI
Plessey
