WORKABOUT PRO Hand-Held Computer With Windows Mobile 5.0 User Manual 321
Chapter 9: Peripheral Devices & Accessories
Automotive Power Adaptor
9.9 Automotive Power Adaptor
Figure 9.15 Automotive Adaptor
The automotive power adaptor, model number WA3112-G1, is an optional
accessory that allows you to power your WORKABOUT PRO through your vehicle
cigarette lighter.
• Attach a tether cable to the base of the WORKABOUT PRO.
• Insert the automotive lighter adaptor DC power plug into the DC IN socket
on the tether cable.
• Insert the adaptor in your vehicle cigarette lighter outlet to power your unit.
9.10 The Vehicle Cradle
The vehicle cradle is a highly ruggedized, single station dock. Although it provides
quick insertion and removal, the cradle holds the WORKABOUT PRO securely
even when operated in high vibration environments.
Automotive Power Adaptor
Fuse
Tether
Connector
Tether
Cable
Tether
Port
DC IN SocketDC IN Socket
DC Power Plug
