Using Web Interface to Manage the Access Point AP-800 User Guide
Managing the Device
83
Click OK to initiate the process.
• If the operation is completed successfully the device would provide the information about the successful update.
Figure 6-42 Update Device Using TFTP- Success Message
• If the operation is not completed successfully the following screen appears, and the reason for the failure is
displayed.
Figure 6-43 Update Device Using TFTP- Failure Message
Retrieve From Device Using HTTP
Use the HTTP Upload page to retrieve config files from device.
1. Select the type of file (config, event log) from the File Type drop-down box.
2. Click Retrieve button to initiate the process.
Figure 6-44 Retrieve File using HTTP
3. The Download page is displayed. Click Download to download the file.
