Introduction
This chapter contains information on the following:
• Products Covered in this User Guide
• About AP-800 Single Radio Wireless Access Point
• Core Features of AP-800
– Two Independent Multi-Band MIMO Radios
– 802.11n Multiple Input and Multiple Output (MIMO)
– Security
– Quality of Service (QoS)
– Software Upgrade
– Compliant to Wireless Standards
Products Covered in this User Guide
This User Guide details functionality of the following products:
About AP-800 Single Radio Wireless Access Point
The AP-800 is 802.11n single radio wireless Access Point that provides connectivity between wired network and
wireless systems and other devices. The AP-800 wireless Access Point is a Wi-Fi a/b/g/n certified that supports single
radio modes in 2.4 GHz and 5 GHz frequency band. You can configure the radio using different 2.4 GHz or 5 Ghz
settings.
With AP-800, you can achieve higher throughput by increasing the channel width from 20 MHz to 40 MHz thereby
doubling the data rate and by using the MIMO feature. The 802.11n products have incorporated multiple antennas. This
Multiple-Input, Multiple-Output (MIMO) antenna technology provides spatial multiplexing, short Guard Interval(GI) for
increased range and throughput.
Using the Channel Bonding technique, the Access Point uses two separate adjacent 20MHz bands to transmit data. This
increases the amount of data that can be transmitted.
NOTE: Wherever “n” is mentioned, it refers to the Draft 802.11n Version 2.0.
Product Description
AP-800 An Access Point with:
• single radio that supports 2.4/5.0GHz
• Gigabit Ethernet with PoE support
