Access Point Features AP-800 User Guide
Monitoring the Device
54
• In Nucast Packets: The number of non-unicast (i.e., subnetwork-broadcast or subnetwork-multicast) packets
delivered to a higher-layer protocol.
• In Errors: The number of inbound packets that contained errors preventing them from being deliverable to a
higher-layer protocol.
• Out Octets (bytes): The total number of octets transmitted out of the interface, including framing characters.
• Out Ucast Packets: The total number of packets that higher-level protocols requested be transmitted to a
subnetwork-unicast address, including those that were discarded or not sent.
• Out Discards: The number of error-free outbound packets chosen to be discarded to prevent their being transmitted.
One possible reason for discarding such a packet could be to free up buffer space.
• Out Errors: The number of outbound packets that could not be transmitted because of errors.
Network Layer
This page provides information of the IP ARP and for the received and transmitted messages.
RADIUS
Authentication Statistics
The feature description are:
• Round Trip Time: This parameter represents the round trip time for messages exchanged between radius client
and authentication server since client startup.
• Stats Requests: This parameter represents the number of RADIUS Access Requests messages transmitted from
the client to the server since client startup.
• Retransmissions: This parameter represents the number of RADIUS Access Requests messages retransmitted
from the client to the server since client startup.
• Access Accepts: This parameter indicates the number of RADIUS Access Accept messages received since
system startup.
• Access Rejects: This parameter represents the number of RADIUS Access Rejects messages received since the
system startup.
• Access Challenges: This parameter represents the number of RADIUS Access Challenges messages received
since the system startup.
• Stats Responses: This parameter represents the total number of RADIUS Access messages received from the
authentication server since system startup.
• Malformed Responses: This parameter represents the number of malformed RADIUS Access Response
messages received since system satrtup.
• Bad Authenticators: This parameter represents the number of malformed RADIUS Access response messages
containing invalid authenticators received since system startup.
• Timeouts: This parameter represents the total number of timeouts for RADIUS Access Request messages since
system startup.
• Unknown Types: This parameter represents the number of messages with unknown Radius Message Code
since system startup.
• Packets Dropped: This parameter represents the number of Radius message which do not contain any EAP
payloads or EAP State machine do not have any valid EAP state data since system startup.
Accounting Statistics
The feature description are:
• Round Trip Time: This parameter represents the round trip time for messages exchanged between radius client
and accounting server since client startup.
