Access Point Features AP-800 User Guide
Managing the Device
48
Static MAC Address Filter
• Wired MAC Address: This parameter represents the MAC address for the filter wired address.
• Wired MAC Mask: This parameter represents the MAC address for the filter wired Mask.
• Wireless MAC Address: This parameter represents the MAC address for the filter wireless address.
• Wireless MAC Mask: This parameter represents the MAC address for the filter wireless Mask.
• Comment: This parameter is used for entering the comment for the Static MAC filter table and this ia an optional
parameter.
Advanced Filtering
• Protocol Name: This parameter is used to represent the protocol name that is to be filtered.
• Direction: This parameter represents the direction of the individual entry in the advanced filter table. The direction can
be enabled either for Ethernet to Wireless, Wireless to Ethernet or both ways.
TCP/UDP Port Filter
• Filter Control: This parameter is used for configuring the status for the TCP/UDP port filter.
• Protocol Name: This parameter is used to configure the protocol name.
• Port Number: This parameter represents the TCP/UDP port filter number.
• Port Type: This parameter represents the port type for this TcpUdp Port filter table entry. The object can be either TCP
or UDP or TCP/UDP.
• Filter Interface: This parameter is used to configure the interface. By default, the object is set to All Interfaces. The
filter can be enabled either for Ethernet, Wireless or All Interface.
For more information on how to configure the above mentioned features, refer the following chapters:
• Using Web Interface: Using Web Interface to Manage the Access Point
• Using SNMP Interface: Using SNMP Interface to Manage the Access Point
• CLI Interface: Using CLI to Manage the Access Point
Managing the Device
Following features are available under Device Management:
System Information
This feature of the Access Point provides system specific information such as system name and contact information. It
also provides the inventory management information such as Access Point’s hardware, software, version and other
information about the AP’s installed components.
System Information Features
• System Up-Time: This is a read-only field that displays how long the Access Point has been running since its last
reboot.
• System Description: This parameter provides the description of the system. This is a read-only field that reports the
Access Point’s name, serial number, current image software version, and current bootloader software version.
• System Name: This parameter provides the system name that is assigned. By default this displays the complete
domain name.
• Email: The email address of the person responsible for the AP.
• Phone Number: The phone number of the person responsible for the AP.
• Location: The location where the AP is installed.
