Installation and Initialization AP-800 User Guide
Installing the Software
23
Figure 2-13 Update Device Using TFTP- Success Message
• If the operation is not completed successfully the following screen appears, and the reason for the failure is
displayed.
Figure 2-14 Update Device Using TFTP- Failure Message
Retrieve From Device
Using HTTP
Use the HTTP Upload page to retrieve config files from device.
1. Select the type of file (config, event log) from the File Type drop-down box.
2. Click Retrieve button to initiate the process.
Figure 2-15 Retrieve File using HTTP
3. The Download page is displayed. Click Download to download the file.
