Specifications AP-800 User Guide
Hardware Specifications
136
Network Features
Hardware Specifications
Feature Supported by AP-800 (Y/N)
System Logging (Syslog) Y
RADIUS Accounting Support* Y
DHCP Client Y
TCP/IP Protocol Support Y
Category Specification
Radio • Dual Radio Access Point with integrated radios: 802.11a/b/g/n + 802.11a/b/g/n
• 3x3 MIMO
Wireless Protocol • 802.11n draft 2.0
• 802.11a
• 802.11b
• 802.11g
Frequency • 5.15-5.85GHz*
• 2.4-2.483 GHz*
* Subject to Individual Country Regulations
Channel bandwidth • 20MHz and 40MHz for 802.11n
• 20MHz for 802.11a/b/g
RF Modulation • MSC0 - MCS15 for 802.11n (6.5Mbps -300Mbps)
• BPSK, QPSK, 16-QAM and 64-QAM for 802.11a and 802.11g (6Mbps - 54Mbps)
• DSSS for 802.11b (1Mbps -11Mbps)
Device Interface Ethernet: Auto-sensing 10/100/1000BASE-T Ethernet
Antenna Connector: 3RP-SMA connector per radio
Network Architecture
Type
Infrastructure
Transmit Power For 2.4 GHz: 19dBm*
For 5 GHz : 17dBm*
* Varies with modulation scheme
Receive Sensitivity For 2.4 GHz and 5 GHz: -75dBm*
* Varies with modulation scheme
Antennas 6Dual-Band reverse SMA connector Omni-Antenna with 3 dBi gain
Local Configuration
Support
RS-232 Serial port, DB9 Female
Message
Authentication
• 802.11i AES message authentication with 128 bit keys
• TKIP with 128 bit Michael Message Integrity Check
Intrusion detection Detect MIC intrusion attacks
