Specifications AP-800 User Guide
Software Specifications
135
Advanced Bridging Functions
Medium Access Control (MAC) Functions
* DFS is required for 802.11a APs certified in the ETSI, TELEC, FCC, and IC regulatory domains and operating in the
middle frequency band. When ACS is disabled, available channels are limited to those on the lower frequency band.
Security Features
* Key lengths supported by 802.11a/4.9 GHz: 64-bit, 128-bit, and 152-bit.
Key lengths supported by 802.11b: 64-bit and 128-bit.
Key lengths supported by 802.11b/g: 64-bit, 128-bit, and 152-bit.
Feature Supported by AP-800 (Y/N)
IEEE 802.1d Bridging Y
Roaming Y
Protocol Filtering Y
Multicast/Broadcast Storm Filtering Y
TCP/UDP Port Filtering Y
Blocking Intra BSS Clients Y
Packet Forwarding Y
Feature Supported by AP-800 (Y/N)
Automatic Channel Selection (ACS) Y
Dynamic Frequency Selection (DFS)/Radar
Detection (RD)*
Y
Wireless Service Shutdown Y
802.11d Support Y
Tx Power Control Y
Wireless Multimedia Enchancements/Quality
of Service (QoS)
Y
Broadcast Unique Beacon Y
Feature Supported by AP-800 (Y/N)
RADIUS Profiles per VLAN Y
IEEE 802.11 WEP* Y
MAC Access Control Y
RADIUS MAC-based Access Control Y
IEEE 802.1x Authentication† Y
Wi-Fi Protected Access (WPA)/802.11i (WPA2) Y
