Installation and Initialization AP-800 User Guide
System Requirements
13
System Requirements
To begin using an AP, you must have the following minimum requirements:
• Ethernet switch or cross-over Ethernet cable.
• One of the following IEEE 802.11- compliant devices:
– An 802.11a/b/g or 802.11n client devices
• A computer that is connected to the same IP network as the AP and has one of the following installed:
– Web browser
– Telnet
– RS-232 Serial Port
– MIB Browser
– Ethernet NIC Card
Product Package
Each AP-800 shipment includes the items in the following table. Verify that you have received all parts of the shipment.
NOTE: Unless noted in this table, cables are not supplied with the unit.
AP-800 Product Package Description Images
AP-800 unit with (1 Qty):
– one radio (802.11a/b/g/n) support
– Ethernet port with PoE support (10/100/1000)
CD-ROM containing software and documentation (1
Qty)
Quick Install Guide (1 Qty)
2.4 GHz/ 5GHz omni-directional antennas with reverse
SMA connectors (6 Qty)
Cable Security Cover (1 Qty)
Wall/Ceiling mount plate (1 Qty)
