Installation and Initialization AP-800 User Guide
Prerequisites
12
Description of the AP-800 Unit
Figure 2-3 Schematic Illustration of the Unit
Prerequisites
Before installing your unit, you need to gather certain network information. The following table identifies the information
you need:
AP’s IP Address If you do not have a DHCP server on your network, then you need to assign the
Access Point an IP address that is valid on your network.
Web Interface/Telnet/CLI User
Name/Password
Each Access Point requires a read/write username and password to access the
web interface, Telnet and CLI. The default username is “admin” and password is
“public”.
SNMP Read Password Each Access Point requires a password to allow get requests from an SNMP
manager. The default username is “admin” and password is “public”.
SNMP Read-Write Password Each Access Point requires a password to allow get and set requests from an
SNMP manager. The default password is “public”.
Security Settings You need to determine what security features you will enable on the Access
Point.
Gateway IP Address and Subnet
Mask
The gateway IP address and subnet mask of the network environment where the
Access Point is deployed.
