AP- 800 User Guide
2
Installation and Initialization
In this chapter:
Hardware Overview
LED Indicators
Antennas
Power Socket
Reset
Reload
Description of the AP-800 Unit
Prerequisites
System Requirements
Product Package
Optional Accessories
Hardware Installation
Attach the Cables
Install the Cable Security Cover (Optional)
Install the Antenna
Mount the Unit
Power on the Unit
Initialization
Using ScanTool
Installing the Software
Install Software Using TFTP Server
Hardware Overview
The Access Point supports dual radio operations using the 2.4 or 5 GHz, and has three antenna connectors. The 2.4
GHz radios support 802.11b/g and 802.11n/g modes of operation whereas 5 GHz radio supports 802.11n/a, and the
802.11n.
LED Indicators
The top panel of the AP-800 has the following LED indicators:
The Power LED provides whether the device is switched on/off.
The Ethernet LED signals Ethernet traffic on the wired Ethernet LAN
The Wireless Interface (Radio) 1LED provides the status of the wireless radio.
The Wireless Interface (r) LED is reserved for future reference.
