Device Management
ORiNOCO® 802.11n Access Points - Software Management Guide 96
: The file name should not contain any spaces or special characters.
3. Click Update, to update the device with new configuration file.
4. Click Load, to apply the updated changes.
5. Click Update & Load, to update and load the configuration file on the device with a single operation.
:
• Reboot the device when you update the device with Binary Configuration file.
• For a Text Based Configuration File, either Update and Load the device or click Update & Load.
• It is recommended not to navigate away from the update screen while the update is in progress.
6.2.2.2 Update Configuration by Using TFTP
To update the device with configuration files by using TFTP, follow the following steps:
1. Navigate to MANAGEMENT > File Management > Update Configuration > TFTP.
2. You can update the device with two configuration files: Binary Config and Text Based Config.
3. To update the device with Binary Configuration file, select Binary Config radio button, the configuration screen
appears.
Figure 6-7 Update Configuration by using TFTP - Binary Config
Configure the following parameters.
Parameter Description
Server IP Address Specifies the IP Address of the TFTP server.
To configure, enter the Server IP Address.
File Name Specifies the name of the Binary file (including the file extension) that has to be
downloaded onto the device.
To configure, enter the Binary File Name with extension.
