Device Management
ORiNOCO® 802.11n Access Points - Software Management Guide 93
6.2 File Management
By using File Management feature, you can update the firmware or configuration files on the device, and retrieve
configuration files from the device through HTTP or TFTP.
HTTP file transfer can be performed with or without SSL enabled. HTTP file transfer with SSL requires enabling Secure
Management and Secure Socket Layer. HTTP file transfer by using SSL may take extra time.
A TFTP server must be running and configured to point to the directory containing the file. The TFTP server must be running
and configured in the desired directory path to copy the retrieved file.
Parameter Description
Product Description Specifies the description of the device.
Number of Radios Specifies the number of radios that the device is licensed to operate.
Number of Ethernet
Interfaces
Specifies the number of ethernet interfaces available on the device.
Radio 1 allowed
‘Frequency Band’
Specifies the operational wireless frequency band supported by the device on Radio 1.
Radio 2 allowed
‘Frequency Band’
Specifies the operational wireless frequency band supported by the device on Radio 2.
: Radio 2 is applicable only to a dual-radio device.
Maximum Output
Bandwidth
Specifies the maximum output bandwidth limit of the device. It is represented in Mbps.
Maximum Input
Bandwidth
Specifies the maximum input bandwidth limit of the device. It is represented in Mbps.
: The Input and Output Bandwidth features are referred with respect to the wireless
interface. That is, input bandwidth refers to the data received on the wireless
interface and output bandwidth refers to the data sent out of the wireless interface.
Maximum
Aggregate
Bandwidth
Specifies the cumulative bandwidth of the device which is the sum of configured output and
input.
Product Family Specifies the product family of the device.
Product Class Specifies the product class of the device. ORiNOCO® 802.11n Access Points are indoor
devices.
Allowed Operational
Modes of Radio 1
Specifies the operational modes allowed on the wireless interface (radio) 1.
Allowed Operational
Modes of Radio 2
Specifies the operational modes allowed on the wireless interface (radio) 2.
: Radio 2 is applicable only to a dual-radio device.
MAC Address of the
Device
Specifies the MAC address of the device.
