Device Configuration
ORiNOCO® 802.11n Access Points - Software Management Guide 87
Figure 5-47 DHCP Server
Tabulated below are the ‘DHCP Server’ parameters and the method to configure the configurable parameters:
Parameter Description
DHCP Server Status Specifies the status of the DHCP Server functionality on the device.
By default, it is disabled. To configure, select Enable or Disable from the drop down menu.
: If DHCP Server Status is enabled, it is recommended to set the IP address manually
(Static IP Address). See Assigning the IP Address Manually
Max Lease Time Specifies the Maximum Lease time for which the DHCP client can have the IP address
provided by the DHCP Server.
By default, the Max Lease Time taken is 86400 seconds. To configure, enter a value
ranging from 3600-172800 seconds.
Max Lease Time
: If the Maximum Lease time is greater than Default Lease time, then the DHCP server
offers the interface based configured Default Lease time. Whereas, if the Maximum
Lease time is less than the Default lease time, then the lease time offered by the
DHCP server will be Maximum Lease time.
DHCP Interface Settings
The DHCP Interface Settings Table contains the following information:
Subnet Mask Specifies the subnet mask to be sent to the client along with the assigned IP address. The
netmask configured here should be greater than or equal to the netmask configured on the
interface. To configure, enter the Net Mask.
