Device Configuration

ORiNOCO® 802.11n Access Points - Software Management Guide 64

Click OK and COMMIT, to save the configured parameters.

5.6.2 802.1d to IP DSCP

Navigate to CONFIGURATION > QoS > 802.1d to IP DSCP. The 802.1d to IP DSCP Mapping Table screen appears.

CW Min Specifies the minimum value for Contention Window (CW) for the wireless QoS EDCA

profile. To configure, enter the CW Min in the range of 0 to 32767, for both wireless client

and AP device.

CW Max Specifies the maximum value for Contention Window (CW) for the wireless QoS EDCA

profile. To configure, enter the CW Max in the range of 0 to 32767, for both wireless client

and AP device.

AI FSN Specifies the Arbitration Inter-Frame Space Number (AI FSN) per access category. To

configure, enter the AI FSN in the range of 2 to 15 for wireless client and 1 to 15 for AP.

TxOP The Transmission Opportunity Limit (TxOP) is an interval during which a particular QoS

enhanced client has the right to initiate a frame exchange on the wireless medium. The TxOP

Limit defines the upper limit based on the TxOP value a wireless entity can obtain for a

particular access category.

To configure, enter the TxOP in the range of 0 to 8160, for both wireless client and AP

device.

ACM The Admission Control Mandatory (ACM) defines if an AP device accepts or rejects a request

traffic stream with certain QoS specifications, based on available channel capacity and link

conditions.

To configure ACM for each access category, select either Enable or Disable from the drop

down menu

Access
