Device Monitoring
ORiNOCO® 802.11n Access Points - Software Management Guide 123
The ICMP Statistics screen contains the following information:
Click Refresh, to view updated ICMP statistics.
7.6 RADIUS
7.6.1 Authentication Statistics
Authentication Statistics provides information on RADIUS Authentication for both the primary and backup servers for each
RADIUS server profile.
To view Authentication statistics, navigate to MONITOR > RADIUS > Authentication Statistics. The RADIUS Client
Authentication Statistics screen appears.
Parameter Description
In Msgs/Out Msgs Specifies the number of ICMP messages that are received/transmitted by the device.
In Errors/Out Errors Specifies the number of ICMP messages that are received/transmitted by the device but
determined as having ICMP-specific errors such as Bad ICMP checksums, bad length and so
on.
In Dest
Unreachs/Out Dest
Unreachs
Specifies the number of ICMP destination unreachable messages that are
received/transmitted by the device.
In Time Excds/Out
Time Excds
Specifies the number of ICMP time exceeded messages that are received/transmitted by the
device.
In Parm Probs/Out
Parm Probs
Specifies the number of ICMP parameter problem messages that are received/transmitted by
the device.
In Src Quenchs/Out
Src Quenchs
Specifies the number of ICMP source quench messages that are received/transmitted by the
device.
In Redirects/Out
Redirects
Specifies the rate at which the ICMP redirect messages are received/transmitted by the
device.
In Echos Specifies the rate at which the ICMP Echo messages are received.
In EchoReps/Out
EchoReps
Specifies the rate at which the ICMP echo reply messages are received/transmitted by the
device.
In Timestamps/Out
Timestamps
Specifies the rate at which the ICMP timestamp (request) messages are received/transmitted
by the device.
In Timestamp
Reps/Out Timestamp
Reps
Specifies the rate at which the ICMP timestamp reply messages are received/transmitted by
the device.
In Addr Masks/Out
Addr Masks
Specifies the number of ICMP address mask request messages that are received/transmitted
by the device.
In Addr Mask
Reps/Out Addr Mask
Reps
Specifies the number of ICMP address mask reply messages that are received/transmitted by
the device.
