Device Monitoring
ORiNOCO® 802.11n Access Points - Software Management Guide 116
View the following Interface statistics and VAP specific statistics.
Click Refresh to view the updated Interface statistics (Ethernet/Wireless 1/Wireless 2) and click Clear to clear the interface
statistics.
: Wireless interface 2 is only applicable to a dual-radio device.
7.2 Station Statistics
Station Statistics allows you to monitor the status of the wireless clients associated with the device.
To view the station statistics, navigate to MONITOR > Station Statistics. The Station Statistics screen appears.
Wireless 1/Wireless 2 Interface Statistics
Parameter Description
Operational Status Specifies the current operational status of the interface.
In Errors Specifies the number of inbound packets with errors and that are restricted from being
delivered.
Out Errors Specifies the number of outbound error packets that are not allowed to transmit.
Tx Multicast Frames Specifies the total number of multicast frames transmitted
Tx Discarded Frames Specifies the total number of multicast frames discarded.
Tx Retry Count Specifies the total number of frames delivered with one or more retransmissions.
Tx RTS Frames Specifies the total number of requests for the RTS frames transmission.
Tx RTS Failures Specifies the total number of RTS frames requests that receive no response.
Tx Fragment Count Specifies the total number of transmitted and acknowledged fragments.
Rx Fragment Count Specifies the total number of fragments transmitted and received successfully.
Tx Failed Count Specifies the total number of undelivered frames.
Duplicate Frame
Count
Specifies the total number of frames transmitted successfully, in a duplicate fragment.
VAP Statistics
In Octets Specifies the total number of octets received on the interface.
In Unicast Packets Specifies the number of unicast subnetwork packets delivered at the higher level protocol.
In Non - Unicast
Packets
Specifies the number of non-unicast subnetwork packets delivered at the higher level
protocol.
Out Octets Specifies the total number of octets transmitted out of the interface.
Out Unicast Packets Specifies the total number of packets requested by the higher level protocol and then
transmitted to the non-unicast address.
Out Discards Specifies the number of error-free outbound packets which are discarded to prevent them
from being transmitted. One possible reason for discarding such a packet could be to free up
buffer space.
