Device Monitoring
ORiNOCO® 802.11n Access Points - Software Management Guide 114
Figure 7-1 Ethernet Interface Statistics
To view Ethernet statistics, click Ethernet in the Interface Statistics screen. The following Ethernet statistics are displayed.
Ethernet Interface Statistics
Parameter Description
Type Specifies the type of interface.
MTU Specifies the largest size of the data packet sent on the bridge.
Physical Address Specifies the MAC address at the interface protocol layer.
Operational Status Specifies the current operational status of the ethernet interface.
In Octets Specifies the total number of octets received on the interface.
In Unicast Packets Specifies the number of unicast subnetwork packets delivered at the higher level protocol.
In Non-Unicast
Packets
Specifies the number of non-unicast subnetwork packets delivered at the higher level
protocol.
In Errors Specifies the number of inbound packets with errors and that are restricted from being
delivered.
Out Octets Specifies the total number of octets transmitted out of the interface.
Out Unicast Packets Specifies the total number of packets requested by the higher level protocol and then
transmitted to the non-unicast address.
