Specifications AP-4000 Series User Guide
Hardware Specifications
220
Hardware Specifications
Physical Specifications
Dimensions (H x W x L) = 6.5 x 18.5 x 26 cm (2.5 x 7.25 x 10.25 in.)
Weight = 1.75 Kg (3.5 lb.)
Electrical Specifications
Voltage = 100 to 240 VAC (50-60 Hz)
Current = 0.2 amp
Power Consumption = <9 Watts (power supply)
Environmental Specifications
Operating = 0°C to 55°C (32°F to 131°F) @ 5 to 95% relative humidity, non-condensing at 5°C and 55°C
Storage = -20°C to 85°C (-4°F to 185°F) @ 5 to 95% relative humidity, non-condensing at 5°C and 85°C
Ethernet Interface
10/100 Base-TX, RJ-45 female socket
Serial Port Interface
Standard RS-232C interface with DB-9, female connector
Active Ethernet Interface
Category 5, foiled, twisted pair cables must be used to ensure compliance with FCC Part 15, subpart B,
Class B requirements
Standard 802.3af pin assignments
