Command Line Interface (CLI) AP-4000 Series User Guide
Parameter Tables
210
Security Profile Table
The Security Profile Table allows you to configure security profiles. A maximum of 16 security profiles are supported per
wireless interface.
Each security profile can be enable and configure one or more security modes (None Secure Station, WEP Station,
802.1x Station, WPA Station, WPA-PSK Station). The WEP/PSK parameters are separately configurable for each security
mode. See the command examples below for more information.
Name Type Value Access CLI Parameter
Hardware Configuration
Reset Status
Integer enable (1)
disable (2)
R hwconfigresetstatus
Configuration Reset
Password
DisplayString User Defined RW configresetpasswd
Name Type Value Access CLI Parameter
Security Profile Table Table N/A R secprofiletbl
Table Index Integer 1.1 to 32.5 R index
Security Mode Integer nonsecsta
wepsta
802.1xsta
wpasta
wpapsksta
Rsecmode
Authentication Mode Integer none
802.1x
psk
R authmode
Cipher Integer none
wep
tkip
aes
R ciphersuite
Encryption Key 0 Integer User defined W encryptionkey0
Encryption Key 1 Integer User defined W encryptionkey1
Encryption Key 2 Integer User defined W encryptionkey2
Encryption Key 3 Integer User defined W encryptionkey3
Encryption Transmit Key Integer 0 - 3 RW encryptkeytx
Encryption Key Length Integer 64, 128, or 152 RW encryptkeylength
Rekey Interval Integer RW rekeyint
WPA PSK Value Integer W pskkey
WPA PSK Pass Phrase Integer 8 - 64 characters W passphrase
