Command Line Interface (CLI) AP-4000 Series User Guide
Parameter Tables
201
Auto Configuration Parameters
These parameters relate to the Auto Configuration feature which allows an AP to be automatically configured by
downloading a specific configuration file from a TFTP server during the boot up process.
TFTP Server Parameters
These parameters relate to upload and download commands.
When a user executes an upload and/or download Command, the specified arguments are stored in TFTP parameters
for future use. If nothing is specified in the command line when issuing subsequent upload and/or download commands,
the stored arguments are used.
IP Access Table Parameters
When creating table entries, you may either specify the argument name followed by argument value or simply entering
the argument value. When only the argument value is specified, then enter the values in the order depicted by the
following table. CLI applies default values to the omitted arguments. Due to the nature of the information, the only
argument that can be omitted is the “comment” argument.
Name Type Value Access CLI Parameter
Auto Configuration Group N/A R autoconfig
Auto Configuration Status Integer enable (default)
disable
RW autoconfigstatus
Auto Config File Name DisplayString User Defined RW autoconfigfilename
Auto Config TFTP Server
IP Address
IpAddress User Defined RW autoconfigTFTPaddr
Name Type Value Access CLI Parameter
TFTP Group N/A R tftp
TFTP Server IP Address IpAddress User Defined RW tftpipaddr
TFTP File Name DisplayString User Defined RW tftpfilename
TFTP File Type Integer img
config
bootloader
sslcertificate
sslprivatekey
sshprivatekey
sshpublickey
clibatchfile (CLI Batch
File)
cbflog (CLI Batch Error
Log)
RW tftpfiletype
Name Type Value Access CLI Parameter
IP Access Table Table N/A R mgmtipaccesstbl
Table Index Integer User Defined N/A index
IP Address IpAddress User Defined RW ipaddr
IP Mask IpAddress User Defined RW ipmask
Comment (optional) DisplayString User Defined RW cmt
Status (optional) Integer enable (default)
disable
delete
RW status
