Command Line Interface (CLI) AP-4000 Series User Guide
Parameter Tables
191
Interface Parameters
Wireless Interface Parameters
The wireless interface group parameter is wif. Wireless Interface A (802.11a radio) uses table index 3 and Wireless
Interface B (802.11b/g radio) uses table index 4.
Common Parameters to 802.11a/b/g
* For 802.11a APs certified in the ETSI and TELEC regulatory domains and operating in the middle frequency band, disabling Auto Channel
Select will limit the available channels to those in the lower frequency band.
† Wireless Service Status cannot be shut down on an interface where Rogue Scan is enabled.
‡ Distance Between APs allows the AP to perform better in high noise environments by increasing the recieve sensitivity and transmit defer
threshold, as follows:
Name Type Value Access CLI Parameter
Wireless Interfaces Group N/A R wif
Table Index Integer 3 (Wireless Interface A) or 4
(Wireless Interface B)
R index
Network Name DisplayString 1 - 32 characters
My Wireless Network (default)
RW netname
Auto Channel Select (ACS)* Integer enable (default)
disable
RW autochannel
DTIM Period Integer 1 - 255
1 = default
RW dtimperiod
RTS/CTS Medium
Reservation
Integer 0 - 2347
Default is 2347 (off)
RW medres
MAC Address PhyAddress 12 hex digits R macaddr
Closed System Integer enable
disable (default)
RW closedsys
Wireless Service Status
†
Integer 1 = resume
2 = shutdown
RW wssstatus
Supported Frequency
Channels
Octet String Depends on Regulatory
Domain
R suppchannels
Load Balancing Max Clients Integer 1 - 63 RW lbmaxclients
Distance Between APs
‡
Integer 1 (large) (default)
2 (medium)
3 (small),
4 (minicell)
5 (microcell)
RW distaps
Antenna Diversity
§
Integer 1 (Antenna 1),
2 (Antenna 2),
3 (Antenna 3),
§
4 (Antenna 4),
5 (Auto; both antennas on
radio)
(See Configure Antenna
Diversity)
RW atdiversity
AP Link Length** Integer 200 (default) - 15000 RW aplinklength
Distance Between
APs
Receive Sensitivity Threshold Transmit Defer Threshold
Value dBm Value dBm
Large 0 -96 33 -62
Medium 9 -86 33 -62
Small 17 -78 43 -52
