3.6 Mounting the LYNX.sc
The LYNX.sc radio can be mounted at any height in a standard 19-inch rack. Blank rack-mounting
spaces above and below the LYNX.sc are recommended, especially if the surrounding equipment
dissipates a considerable amount of heat (over 50W).
The LYNX.sc radio may be set up for mounting with the front edge projecting from the front face of a
standard 19-inch rack using the rack mounting brackets enclosed with the screws in the Accessory
Kit (4 per bracket). The rack mounting brackets may be reversed, in order to install for flush or
cabinet mounting if preferred. Depending on rack configuration, it may be necessary to remove the
four adhesive backed rubber feet on the bottom of the unit.
The LYNX.sc radio has internal fans which intake and exhaust
on the left and right sides of the chassis. When rack mounting,
it is important to leave a small gap between the outer edges of
the radio and the inside edge of the rack.
The LYNX.sc radio may alternatively be placed on a table or shelf
attached to a wall. Because of the low weight of the LYNX.sc, any
mounting option other than rack mounting will be less secure.
