PAGE 2-22 SECTION 2: PRODUCT DESCRIPTION
2.5 Installation Accessories
The LYNX.sc radio is shipped with several accessories commonly required for the radio as
described below:
AC Power
Supply
If ordered as an option, this power supply provides AC to DC conversion for use with
AC powered locations.
AC Power
Cord
This power cord connects the AC Power Supply, if ordered, to a standard 115V U.S.
AC outlet.
Rack Mount
Brackets
Two brackets (along with required mounting screws) are provided which allow 19-
inch rack mounting of the LYNX.sc radio.
Terminal
Connector
This is a 6-pin mating connector used for DC power supply.
D
Connector
9-pin
Two of these mating connectors are provided. One is used for the DIAGNOSTICS
port interface and another for the AUX DATA port.
D
Connector
25-pin
There are 2 mating connectors provided, one for the ALARM interface and the other
for the VF interface.
RF Power
Adjustment
Cover
A small plastic cap is provided which is placed over the RF output power adjustment
receptacle once output power has been set by professional installation personnel.
Other accessories are available, such as orderwire handsets, connector adapters and special
cables. These can be ordered separately upon request.
