User's Manual

INSTALLATION AND MAINTENANCE MANUAL
LYNX.sc E1 FAMILY
SPREAD SPECTRUM RADIOS
SEPTEMBER 1999
PAGE 2-6 SECTION 2: PRODUCT DESCRIPTION
System (Single Hop Performance)
Transmit Frequencies
Channel 2.4 GHz 1xE1 2.4 GHz 4xE1 5.8 GHz 1xE1 5.8 GHz 2xE1 5.8 GHz 4xE1
A1 2410 MHz 2405 MHz 5735 MHz 5730 MHz 5735 MHz
A2 2453 MHz 2446 MHz 5800 MHz 5795 MHz 5800 MHz
B1 2430 MHz 2412 MHz 5755 MHz 5740 MHz 5755 MHz
B2 2473 MHz 2453 MHz 5820 MHz 5805 MHz 5820 MHz
C1 N/A 2419 MHz 5775 MHz 5750 MHz 5775 MHz
C2 N/A 2460 MHz 5840 MHz 5815 MHz 5840 MHz
D1 N/A 2426 MHz N/A 5760 MHz N/A
D2 N/A 2467 MHz N/A 5825 MHz N/A
E1 N/A N/A N/A 5770 MHz N/A
E2 N/A N/A N/A 5835 MHz N/A
F1 N/A N/A N/A 5780 MHz N/A
F2 N/A N/A N/A 5845 MHz N/A
Receive Frequencies
Channel 2.4 GHz 1xE1 2.4 GHz 4xE1 5.8 GHz 1xE1 5.8 GHz 2xE1 5.8 GHz 4xE1
A1 2453 MHz 2446 MHz 5800 MHz 5795 MHz 5800 MHz
A2 2410 MHz 2405 MHz 5735 MHz 5730 MHz 5735 MHz
B1 2473 MHz 2453 MHz 5820 MHz 5805 MHz 5820 MHz
B2 2430 MHz 2412 MHz 5755 MHz 5740 MHz 5755 MHz
C1 N/A 2460 MHz 5840 MHz 5815 MHz 5840 MHz
C2 N/A 2419 MHz 5775 MHz 5750 MHz 5775 MHz
D1 N/A 2467 MHz N/A 5825 MHz N/A
D2 N/A 2426 MHz N/A 5760 MHz N/A
E1 N/A N/A N/A 5835 MHz N/A
E2 N/A N/A N/A 5770 MHz N/A
F1 N/A N/A N/A 5845 MHz N/A
F2 N/A N/A N/A 5780 MHz N/A
