User's Manual

INSTALLATION AND MAINTENANCE MANUAL
LYNX.sc E1 FAMILY
SPREAD SPECTRUM RADIOS
SEPTEMBER 1999
PAGE 2-2 SECTION 2: PRODUCT DESCRIPTION
2.2 Specifications
All specifications are subject to change without notice.
2.2.1 Transmitter
All Models
Frequency Selection Rear Panel DIP switches; 7-cavity RF filter assembly
Modulation OQPSK
Coding Direct Sequence
Number of Codes 4 (Rear Panel DIP switch selectable)
2.4 GHz E1 2.4 GHz 2 x E1 2.4 GHz 4 x E1
Output Power (max.) +30 dBm* +30 dBm* +30 dBm*
Output Power (typ.) +27 dBm* +27 dBm* +27 dBm*
Control Range 16 dB min. 16 dB min. 16 dB min.
Frequency Range 2410-2473 MHz 2421-2462.5 MHz 2421-2462.5 MHz
(occupies (occupies (occupies
2400- 2400- 2400-
2483.5 MHz) 2483.5 MHz) 2483.5 MHz)
* 10 dB less on ETSI compliant models
5.8 GHz E1 5.8 GHz 2 x E1 5.8 GHz 4 xE1
Output Power (max.) +23 dBm +23 dBm +23 dBm
Output Power (typ.) +20 dBm +20 dBm +20 dBm
Control Range 20 dB min. 20 dB min. 20 dB min.
Frequency Range 5735-5840 MHz 5741-5834 MHz 5750-5825 MHz
(occupies (occupies (occupies
5725- 5725- 5725-
5850 MHz) 5850 MHz) 5850 MHz)
