Antenna Installation
ORiNOCO
®
AP-9200R - Hardware Installation Guide 50
Step 1: Wrap vinyl tape in a half-lapped fashion, from the weatherproof connector end and continue wrapping down 3
inches onto the CAT5e cable.
a. Weatherproofing at the device end:
b. Weatherproofing at the antenna end:
Step 2: Wrap a second layer of vinyl tape in the reverse direction over the first layer of tape.
a. Weatherproofing at the device end:
b. Weatherproofing at the antenna end:
(a)
(b)
(a)
(b)
(c)
(a) (b)
(a)
(b)
