Installation Guide
Table Of Contents
- Package Contents
- Getting Started
- Device Overview
- Device Installation
- Technical Specifications
- Device Models
- Accessories
- OFDM Modulation Rates
- Wireless Protocol
- Interfaces
- Transmit Power Specifications (5.150 to 5.850) GHz
- Transmit Power Specifications (2.400 to 2.484) GHz
- Receive Sensitivity (5.150 - 5.850) GHz
- Receive Sensitivity (2.400 to 2.484) GHz
- Power Supply
- Hardware Specifications
- Physical Specifications
- Environmental Specifications
- MTBF
- 6 Recommended Antennas
- Antenna Installation
- Measuring Signal Performance
- Lightning Protection
- Abbreviations
- Warranty and Technical Support
- Safety & Regulatory Information
ORiNOCO
®
AP-9200R - Hardware Installation Guide 5
1
Package Contents
Each shipment includes the items listed in the following table. Please verify that you have received all the parts in this
shipment, prior to installation.
What’s in the kit Image
AP9200R
Power Injector with Country
specific Power Cord
WD - US and EU power cords
US - US power cord
2.4 GHz, 7 dBi Omni Antennas
(x 3)
5 GHz, 7 dBi Omni Antennas (x 4)
Connector Weather Proofing Kit
(1 set)
Grounding Kit
