Antenna Installation
ORiNOCO
®
AP-9200R - Hardware Installation Guide 46
– Transmit Power = EIRP - G
(30- 0)
- MIMO Gain
= 21 - 10 = 11 dBm
• Case 3: 0
= -15
0
(antenna tilted downward)
– The antenna gain for 0
= -15
0
is shown in the following figure:
Figure 8-6 Antenna gain at (30- 0
) = 45
0
– Transmit Power = EIRP - G
(30- 0)
- MIMO Gain
= 21 - 0 = 21 dBm
:
• -10 degree indicates that the antenna is tilted downwards.
• 10 degrees indicates that the antenna is titled upwards.
Tilt Angle
(degrees)
Allowed Transmit Power per
Single chain (dBm)
EIRP of Product
(dBm)
Remarks
01237
-10 13 42
-20 13 38
-30 17 42
10 10 35
20 10 35
30 -5 21 Not Recommended
