Recommended Antennas
ORiNOCO
®
AP-9200R - Hardware Installation Guide 28
7.4 Recommended Antennas
:
• To ensure proper installation of antenna(s), refer to Antenna Installation.
• Ensure, you meet all the pre-requisites described in the Antenna Installation, while selecting the antennas and antenna
cables.
• Antennas should be aligned and installed on both the sides of a wireless link, maintaining the same polarization.
• We recommend you to use higher gain antennas for better coverage.
• ORiNOCO
®
AP-9200R Series products requires professional installation.
7.5 Recommended Antenna Specifications
This section illustrates the technical specifications of the following:
• Sector Antenna Specifications
• Panel Antenna Specifications
7.5.1 Sector Antenna Specifications
• 14 dBi Dual Polarized Sector Antenna
• 15.5 dBi Dual Polarized Sector Antenna
: Tabulated below are the antennas that Proxim recommends you to use with the ORiNOCO
®
AP-9200R Series devices. To buy these antennas, place an order separately with your distributor.
Dual - Polarized Antennas
Product(s) Part Number Antenna Type Description
AP-9200R SA5-9014-DP Sector Antenna 4.9 - 5.95 GHz, Dual Polarity, Vertical and Horizontal, 14 dBi Sector
Antenna- 90 degrees. Mounting kit included.
SA5-6015-DP Sector Antenna 4.9 - 6 GHz, Dual Polarity, Vertical /Horizontal, 15.5 dBi Sector
Antenna - 60 degrees. Mounting kit included.
AP-9200R PA5-0823-DP Panel Antenna 4.9 - 5.875 GHz, Dual Polarity, Slanted (±45º) or V/H, 23 dBi Panel
Antenna.
PA5-0530-DP Panel Antenna 4.9 - 6.1 GHz, Dual Polarity, Vertical and Horizontal, 29 dBi Panel
Antenna.
Quad - Polarized Antennas
Product(s) Part Number Antenna Type Description
AP-9200R PA5-1919-QP Panel Antenna 4.9-6.4GHz, Quad Polarity, Vertical/Horizontal/Dual Slant, 19 dBi
Pannel Antenna - 19 degrees. Mounting kit Incd.
: Ensure to use the same antenna specifications listed below, while using any of the non-proxim
antennas.
