Installation Guide

Technical Specifications
ORiNOCO
®
AP-9200R - Hardware Installation Guide 22
Power Supply
Hardware Specifications
Physical Specifications
Environmental Specifications
2.400 - 2.484 GHz
Products Stream Data Rate (Mbps) Receive Sensitivity (dBm)
11b
AP-9200R
Single Stream 1 -93
2-93
5.5 -92
11 -89
Products Category Specification
AP-9200R
Input Voltage
Via RJ45 Ethernet interface supplying 36 - 57 V DC on Ethernet
Port. Power consumption: 27 W typical, 30 W max.
PoE Injector
Input: 100 – 240 V AC (50/60 Hz)
Output: 56 V DC (30 Watts)
*Pin-out: V+ on pins 3/4/5/6, V- on pins 1/2/7/8
Operating Temp: 0º C to +40º C
* Refer supplied PoE model for actual power Pin-out specification.
Products Radio Processor
Speed
Memory Input Power Power Consumption
AP-9200R 5.150 - 5.850 GHz
and 2.400 - 2.484
GHz MIMO radios
720 MHz Flash: 32 MB
RAM: 256 MB
Power-over-Ethernet
36
- 57 V DC
27 W typical,
30 W max
Products Category Specification
AP-9200R Dimensions (L x W x H) 170 x 217 x 56 mm / 6.7 x 8.55 x 2.2 in
Weight 1.20 kg / 2.65 lbs
Products Operating Temperature Storage Temperature Humidity Wind Loading
AP-9200R -30º to 55º Celsius
-22º to 131º Fahrenheit
-50º to 70º Celsius
-58º to 158º Fahrenheit
100% relative humidity
IP67
180 km/h
112.5 mph
