Receive Sensitivity (2.400 to 2.484) GHz
2.400 - 2.484 GHz
Products Stream MCS Index
Modulation
Typ e
Coding Rate
Receive Sensitivity*
11n
HT20
11n
HT40
AP-9200R Single Stream MCS 0 BPSK 1/2 -91 -86
MCS 1 QPSK 1/2 -89 -85
MCS 2 QPSK 3/4 -86 -82
MCS 3 16 QAM 1/2 -83 -80
MCS 4 16 QAM 3/4 -80 -76
MCS 5 64 QAM 2/3 -75 -73
MCS 6 64 QAM 3/4 -73 -71
MCS 7 64 QAM 5/6 -72 -69
Dual Stream
MCS 8 BPSK 1/2 -89 -85
MCS 9 QPSK 1/2 -86 -83
MCS 10 QPSK 3/4 -83 -79
MCS 11 16 QAM 1/2 -79 -77
MCS 12 16 QAM 3/4 -76 -73
MCS 13 64 QAM 2/3 -72 -69
MCS 14 64 QAM 3/4 -70 -67
MCS 15 64 QAM 5/6 -68 -64
Note: Receive Sensitivity values should be considered with a tolerance +/- 2 dB.
2.400 - 2.484 GHz
Products Stream Data Rate (Mbps) Receive Sensitivity (dBm)
11g
AP-9200R
Single Stream 6 -91
9-90
12 -90
18 -87
24 -84
36 -81
48 -76
54 -74
