Installation Guide

Technical Specifications
ORiNOCO
®
AP-9200R - Hardware Installation Guide 20
Transmit Power Specifications (2.400 to 2.484) GHz
Receive Sensitivity (5.150 - 5.850) GHz
2.400 ~ 2.484 GHz
Products Stream MCS Index Modulation
Typ e
Coding
Rate
Tx Power* (dBm)
11n HT20 11n HT40
AP-9200R
Single
stream
(or)
Dual
Stream
MCS 0 (or)
MCS 8
BPSK 1/2 21 20
MCS 1 (or)
MCS 9
QPSK 1/2 21 20
MCS 2 (or)
MCS 10
QPSK 3/4 20 19
MCS 3 (or)
MCS 11
16 QAM 1/2 20 19
MCS 4 (or)
MCS 12
16 QAM 3/4 19 18
MCS 5 (or)
MCS 13
64 QAM 2/3 19 18
MCS 6 (or)
MCS 14
64 QAM 3/4 18 17
MCS 7 (or)
MCS 15
64 QAM 5/6 18 17
Note:
Output Power Attenuation: 0 – 17 dB, in 1 dB steps
Total EIRP must be calculated based on the antenna gain
* Tx Power indicates the power at the radio ports.
Products Stream Modulation Type Coding Rate
Receive Sensitivity*
(dBm)
(5.150 ~ 5.850) GHz
VHT20 VHT40 VHT80
AP-9200R
Dual Stream
BPSK
1/2 -91 -87
-85
QPSK
1/2 -87 -84
-82
QPSK
3/4 -85 -82
-80
16 QAM
1/2 -83 -79
-77
16 QAM
3/4 -78 -75
-73
64 QAM
2/3 -74 -72
-69
64 QAM
3/4 -72 -70
-68
64 QAM
5/6 -70 -67
-67
256QAM
3/4 -68 -64
-62
256QAM
5/6 -66 -62
-59
Note:
• Receive Sensitivity values should be considered with a tolerance +/- 2 dB.
