Installation Guide

Technical Specifications
ORiNOCO
®
AP-9200R - Hardware Installation Guide 19
Transmit Power Specifications (5.150 to 5.850) GHz
Products Stream MCS
Index
Modulation
Type
Coding
Rate
Tx Power* (dBm)
VHT20
(5.15-5.80 GHz)
VHT40
(5.15- 5.80 GHz)
VHT80
(5.15- 5.80 GHz)
AP-9200R
Single
stream
(or)
Dual
Stream
(or)
Quad
Stream
MCS 0
BPSK
1/2
21 20 18
MCS 1
QPSK
1/2
21 20 18
MCS 2
QPSK
3/4
20 19 18
MCS 3
16QAM
1/2
20 19 18
MCS 4
16QAM
3/4
19 18 18
MCS 5
64QAM
2/3
19 18 17
MCS 6
64QAM
3/4
17 17 17
MCS 7
64QAM
5/6
17 16 16
MCS 8
256-QAM
3/4
16 15 15
MCS 9
256-QAM
5/6
NA 15 14
Note:
• Output Power Attenuation: 0 – 17 dB, in 1 dB steps
• For MCS 0, the maximum attenuation limit is 17 dB
• For MCS 9, the maximum attenuation limit is 10 dB
• Total EIRP must be calculated based on the antenna gain
• Tolerance = +/- 2 dB
* Tx Power indicates the power at the radio ports.
* In case of integrated devices, the Tx Power at the antenna ports is 1 dB higher than the above tabulated values.
• In the FCC United States 5.8 GHz band edge frequencies, the Maximum Tx Power of the radio will be restricted based on the FCC
Certification and Antenna Type used. For details refer the Antenna Intallation and Recommendation Guide.
